AIPER Scuba SE Cordless Robotic Pool Cleaner Instruction Manual

1. انتهى المنتجview

The AIPER Scuba SE is a cordless robotic pool cleaner designed for efficient and hassle-free cleaning of above-ground pools up to 860 square feet. It features powerful suction, smart self-parking, and a quick drain system for ease of use and maintenance.

Figure 1: AIPER Scuba SE Cordless Robotic Pool Cleaner

2. الإعداد والشحن

2.1 فك الصندوق والتجميع الأولي

Upon unboxing, ensure all components are present. The Scuba SE typically requires minimal assembly, primarily attaching the brushes if they are not pre-installed. Refer to the included quick start guide for specific assembly instructions.

Figure 2: Attaching brushes to the Scuba SE for assembly.

2.2 شحن الوحدة

Before first use, fully charge the Scuba SE. A full charge takes approximately 3 hours and provides up to 90 minutes of runtime. Ensure the charging port is completely dry before connecting the charger to prevent damage.

• Connect the charger to the unit's charging port.
• قم بتوصيل الشاحن بمأخذ الطاقة.
• سيُظهر مؤشر LED حالة الشحن (على سبيل المثال، أحمر للشحن، وأخضر للشحن الكامل).
• Always ensure the charging port is dry before charging.

Figure 3: Charging the AIPER Scuba SE. The unit charges in approximately 3 hours.

3. تعليمات التشغيل

3.1 Activating the Cleaner

The Scuba SE features one-click activation. Simply press the power button located on the unit to start the cleaning cycle.

Figure 4: One-click activation button on the AIPER Scuba SE.

3.2 Deploying the Unit

Once activated, slowly submerge the Scuba SE into the pool. Allow it to fill with water and sink to the bottom. The unit will begin its cleaning path automatically.

3.3 عملية التنظيف

The Scuba SE operates cordlessly, providing unrestricted movement across the pool floor. Its powerful suction effectively tackles dirt, leaves, and debris. The hydrodynamic design ensures minimal resistance and maximum speed for efficient cleaning.

Figure 5: The Scuba SE demonstrating efficient cleaning in a pool.

Figure 6: The hydrodynamic design of the Scuba SE for optimal movement.

3.4 Smart Self-Parking

When the battery level is low, the Scuba SE will automatically return to the poolside for easy retrieval, eliminating the need to chase it down.

Figure 7: The Scuba SE automatically parking itself at the poolside when the battery is low.

3.5 استعادة عامل النظافة

Use the provided retrieval hook to easily lift the unit out of the water. The quick drain system allows 90% of the water to drain in just 15 seconds, making it lightweight for handling.

Figure 8: Demonstrating the easy retrieval and quick water release of the Scuba SE.

4. الصيانة

4.1 Cleaning the Filter Tray

Regularly clean the filter tray to maintain optimal cleaning performance. Pop off the cover and rinse the filter with a hose.

Figure 9: Cleaning the filter tray of the Scuba SE with a hose.

4.2 Post-Use Care

After each use, ensure the unit, especially the charging port, is completely dry before storing or recharging. This prevents potential damage and prolongs the lifespan of the device.

5. استكشاف الأخطاء وإصلاحها

• Unit not moving or stalling in round pools: The Scuba SE uses bump-and-go steering. In some round pools, it might slide along the wall instead of bumping and reversing. Adjusting the wheel settings (if available) to 'hybrid' mode might help.
• أداء تنظيف ضعيف: Check and clean the filter tray. A clogged filter can significantly reduce suction power.
• Unit not charging: Ensure the charging port is completely dry before connecting the charger. Verify the charger is properly connected and the power outlet is functional.
• Unit not submerging: Ensure the unit is fully filled with water. Slowly submerge it to allow air to escape.

6. المواصفات

7. الضمان والدعم

The AIPER Scuba SE Cordless Pool Cleaner is protected by a 1-year warranty. For any product inquiries, technical assistance, or warranty claims, please contact AIPER customer service through their official webالموقع أو بائع التجزئة الذي تم شراء المنتج منه.
