KERUI 2.4GHz WiFi Water Leak Detector Instruction Manual

1. المقدمة

This manual provides detailed instructions for the installation, operation, and maintenance of your KERUI 2.4GHz WiFi Water Leak Detector. Please read this manual thoroughly before using the device to ensure proper function and safety. This device is designed to detect water leaks and water levels, providing real-time alerts to help protect your home from water damage.

2. انتهى المنتجview

الشكل 2.1: The KERUI Water Leak Detector main unit.

2.1 الميزات الرئيسية

• 3-in-1 Advanced Functionality: Equipped with a top sensor, two bottom sensors, and an extra-long detachable detection cable (105cm) for comprehensive water leak and water level detection. Easily switch between modes by connecting or disconnecting the cable.
• الإشعارات في الوقت الحقيقي: Connects to 2.4GHz WiFi to send instant alerts and notifications to your smartphone via the Tuya Smart app when a leak is detected.
• إنذار عالي الصوت بقوة 100 ديسيبل: Emits a continuous 100dB audible alarm for 60 seconds upon detection, ensuring you are alerted even if not near your phone.
• تصميم مدمج وأنيق: Measuring approximately 65x65x28 mm, the detector is discreet and integrates seamlessly into any home environment.
• تصنيف مقاومة الماء IP67: مقاوم للماء IP67 متينasing and anti-rust coating ensure long-term use in humid environments.

2.2 محتويات العبوة

تأكد من وجود جميع العناصر في الحزمة الخاصة بك:

• KERUI Water Leak Detector
• 105cm External Probe
• Hook and Screws for mounting
• دليل المستخدم
• 4 بطاريات AAA (مضمنة)

الشكل 2.2: The detector unit with its external detection cable.

3. الإعداد

3.1 تركيب البطارية

The device requires 4 AAA alkaline batteries. These are typically pre-installed. To activate, open the battery compartment and remove the protective film from the batteries. Ensure correct polarity when inserting or replacing batteries.

الشكل 3.1: Illustration of battery installation. Open the compartment, insert 4 AAA batteries, ensuring correct polarity.

3.2 تنزيل التطبيق وإقرانه

The KERUI Water Leak Detector operates with the Tuya Smart application. Ensure your smartphone is connected to a 2.4GHz Wi-Fi network before proceeding.

1. تنزيل التطبيق: Scan the QR code provided in the manual or search for "Tuya Smart" in your smartphone's app store (Google Play Store for Android, Apple App Store for iOS).
2. التسجيل/تسجيل الدخول: Open the Tuya Smart app and register a new account or log in with an existing one.
3. إضافة جهاز:
   • Ensure the detector is powered on (batteries installed and protective film removed).
   • In the Tuya Smart app, tap the "+" icon to add a device.
   • Select "Security & Sensor" then "Water Leak Detector (Wi-Fi)".
   • Follow the on-screen instructions to connect the device to your 2.4GHz Wi-Fi network. This usually involves pressing a button on the detector to enter pairing mode.
   • Once connected, you can rename the device for easier identification (e.g., "Kitchen Leak Sensor").

الشكل 3.2: Steps for app download and Wi-Fi pairing. Scan the QR code to download the Tuya Smart app, then follow in-app instructions to connect to your 2.4GHz Wi-Fi network.

Download the Tuya Smart App: https://smartapp.tuya.com/tuyasmart

4. التشغيل

4.1 أنماط الكشف

The detector offers three detection methods:

• Water Leak Detection (Default): The two probes on the back of the alarm detect water. When water bridges these probes, the alarm triggers.
• Drip Detection: A probe on the front of the alarm is designed to detect small drips. Place it directly under a potential drip source.
• مراقبة مستوى المياه: Use the included 105cm external detection cable with two probes to monitor specific water levels. Connect the cable to the detector to activate this mode.

الشكل 4.1: Three usage options for the water immersion alarm. This includes hanging the external probe, placing the unit on the ground to detect leaks from the back sensors, or placing it to detect drips from the front sensor.

4.2 وظيفة التنبيه

When water is detected by any of the sensors, the device will:

• Emit a loud 100dB audible alarm for 60 seconds.
• أرسل إشعارات فورية إلى هاتفك الذكي عبر تطبيق Tuya Smart.

الشكل 4.2: The 100dB alarm is designed to be heard across your home, providing immediate awareness of a water event.

4.3 App Notifications and Remote Monitoring

The Tuya Smart app allows for remote monitoring and management:

• Receive real-time push notifications on your phone when a leak is detected, even when you are away from home.
• View the history and timestamps of all alarm events within the app.
• Share device access with multiple users (family members) through the app.
• App notifications are free. Optional phone call and SMS notifications may incur charges (refer to Tuya app for details).

الشكل 4.3: Remote monitoring and multi-user sharing capabilities through the Tuya Smart app, allowing multiple family members to receive alerts.

الشكل 4.4: Example of real-time water leak notifications received through the Tuya Smart app.

5. التركيب والوضع

The compact design and IP67 rating allow for flexible placement in various locations prone to water leaks.

• المواقع الموصى بها: Near water-containing appliances such as dishwashers, washing machines, water heaters, under sinks, in bathrooms, kitchens, basements, laundry rooms, and near sump pumps.
• خيارات التركيب:
  • وضع الأرض: Simply place the detector on the floor in areas where leaks are likely to occur. Use the back sensors for general leak detection or the front sensor for drip detection.
  • Wall Mounting/Hanging: Utilize the included hook and screws to mount the detector on a wall. The 105cm external probe can then be extended to the desired detection point, such as inside a cabinet under a sink.
• تسمية الأجهزة: Use the Tuya Smart app to name each detector and specify its location (e.g., "Basement Water Heater," "Kitchen Sink") for clear identification of alarm sources.

الشكل 5.1: Examples of suitable locations for installing the KERUI Water Leak Detector.

6. الصيانة

• استبدال البطارية: The app will notify you when battery levels are low. Replace all 4 AAA batteries promptly to ensure continuous protection. Always use new alkaline batteries.
• تنظيف المستشعر: Periodically inspect the detection probes for any dirt, dust, or corrosion. Clean them gently with a soft, dry cloth to ensure optimal sensitivity.
• تحديثات البرامج الثابتة: Check the Tuya Smart app regularly for any available firmware updates for your device. Updates can improve performance and add new features.
• الظروف البيئية: While the device is IP67 rated, avoid prolonged submersion or exposure to extreme temperatures outside its operating range.

7. استكشاف الأخطاء وإصلاحها

8. المواصفات

9. معلومات السلامة

• احتفظ بالجهاز بعيدًا عن متناول الأطفال والحيوانات الأليفة.
• لا تحاول تفكيك الجهاز أو إصلاحه بنفسك. قد يؤدي ذلك إلى إلغاء الضمان وتلفه.
• تخلص من البطاريات المستعملة وفقًا للوائح المحلية. لا تتخلص من البطاريات بإلقائها في النار.
• تأكد من وضع الجهاز على سطح مستقر أو تثبيته بشكل آمن لمنع السقوط العرضي.
• This device is designed to detect water leaks and levels. It is not a substitute for proper plumbing maintenance or flood prevention measures.

10. الضمان والدعم

For any questions, suggestions, or technical support regarding your KERUI Water Leak Detector, please contact KERUI customer service. Refer to the product packaging or the official KERUI webموقع لمعلومات الاتصال.

Information regarding specific warranty periods or repair services is not available in this manual. Please retain your purchase receipt for warranty claims.
