This manual provides instructions for the Retevis H-777 5V 1A USB Charger Adapter. This adapter is designed for charging various compatible devices, including Retevis H-777, RT7, RT19, RT27, RT22, H-777S walkie-talkies, Retekess V112, V115 FM radios, and Retekess T130, TT101 tour guide systems.
It features advanced charging technology with over-power protection, output over-voltage protection, and short-circuit protection to ensure safe charging of your devices.
Image: The Retevis H-777 5V 1A USB Charger Adapter, a compact black wall adapter with a single USB-A port.
معلومات السلامة
- Ensure the adapter is used within its specified voltagالنطاق الإلكتروني (100-240 فولت).
- تجنب تعريض المحول للرطوبة أو درجات الحرارة القصوى.
- Do not attempt to disassemble or repair the adapter.
- يحفظ بعيدًا عن متناول الأطفال.
- Unplug the adapter from the wall outlet when not in use.
الإعداد والتثبيت
Follow these steps to set up and use your Retevis H-777 Charger Adapter:
- Step 1: Connect USB Cable
Insert the USB cable (not included) of your device into the USB-A port of the Retevis H-777 charger adapter.
الصورة: لقطة مقربة view of the Retevis charger adapter, showing the USB-A port where a USB cable can be inserted.
- Step 2: Plug into Wall Outlet
Plug the adapter into a standard wall power outlet (100-240V). Ensure the connection is firm.
Image: The Retevis charger adapter plugged into a multi-outlet power strip, with a USB cable connected to a walkie-talkie charging base.
- الخطوة 3: الاتصال بالجهاز
Connect the other end of the USB cable to your compatible device (e.g., walkie-talkie, radio, or its charging base).
Image: The Retevis charger adapter with a USB cable connected to a walkie-talkie charging base, ready for charging.
تعليمات التشغيل
Once all connections are secure, the adapter will automatically begin charging your device. The charging status (e.g., LED indicators) will typically be displayed on your connected device or its charging base. Refer to your device's specific instruction manual for details on its charging indicators.
The adapter provides a stable 5V 1A output, optimized for efficient and safe charging of compatible electronics.
صيانة
- Clean the adapter periodically with a dry, soft cloth. Do not use liquid cleaners, aerosols, or harsh chemicals.
- قم بتخزين المحول في مكان بارد وجاف بعيدًا عن أشعة الشمس المباشرة والرطوبة عند عدم استخدامه.
- Inspect the adapter and its prongs for any signs of damage, such as cracks or bent prongs, before each use. Discontinue use if damage is observed.
- Avoid wrapping the USB cable too tightly around the adapter, as this can stress the cable and connections.
استكشاف الأخطاء وإصلاحها
- الجهاز لا يشحن:
- Ensure the adapter is securely plugged into a functional wall outlet. Test the outlet with another device if necessary.
- Verify that the USB cable is properly connected to both the adapter and your device/charging base.
- Check if the device itself is functioning correctly and capable of receiving a charge.
- Try using a different USB cable to rule out a faulty cable.
- Test the adapter with another compatible device if possible to determine if the issue is with the adapter or the original device.
- ارتفاع درجة حرارة المحول:
- Unplug the adapter from the wall outlet immediately.
- Ensure there is adequate ventilation around the adapter during use. Avoid covering it or placing it in enclosed spaces.
- Avoid charging in direct sunlight or excessively warm environments.
- If overheating persists after allowing it to cool and ensuring proper ventilation, discontinue use and contact customer support.
تحديد
| ميزة | التفاصيل |
|---|---|
| رقم الموديل | DSA-5PF07-05-FUS 050 100 |
| حجم الإدخالtage | 100-240 فولت تيار متردد، 50/60 هرتز |
| حجم الإخراجtage | 5 فولت تيار مستمر |
| تيار الخرج | 1A |
| أبعاد | 1.89 × 1.34 × 0.83 بوصة (48 × 34 × 21 مم) |
| وزن | 0.92 أونصات (26 جرام) |
| حماية | Over Power, Output Over Voltagهـ، ماس كهربائي |
Image: The Retevis charger adapter with measurements indicating its width (34mm/1.34in) and depth (21mm/0.83in).
Image: The Retevis charger adapter with a measurement indicating its height (48mm/1.89in).
الضمان والدعم
For warranty information or technical support regarding your Retevis H-777 Charger Adapter, please contact Retevis customer service. You can typically find their contact information on their official webالموقع أو من خلال بائع التجزئة الذي تم شراء المنتج منه.
عند الاتصال بالدعم، يرجى إحضار رقم طراز المنتج الخاص بك (DSA-5PF07-05-FUS 050 100) and purchase details readily available to assist with your inquiry.
