DIGOO DG-M1Z 1080P Home Security Camera User Manual

1. المقدمة

This manual provides detailed instructions for the installation, operation, and maintenance of your DIGOO DG-M1Z 1080P Home Security Camera. Please read this manual thoroughly before using the product to ensure proper functionality and safety.

2. انتهى المنتجview

2.1 الميزات الرئيسية

• True 1080P HD Video Quality (2.0MP Image Sensor)
• 130° Wide Angle Lens (2.8mm)
• 11 Pcs IR LED for Night Vision (up to 10m)
• الاتصالات الصوتية ثنائية الاتجاه
• Motion Detection with E-mail Alerts
• وظيفة التحريك والإمالة
• Support for Micro TF Card Slot (up to 64GB) for Local Storage
• ضغط الفيديو H.264
• دعم ONVIF
• Compatible with iOS, Android, and Windows PC via "Digoo Eye" App

2.2 مكونات الكاميرا

The DIGOO DG-M1Z camera features a compact design with essential components for surveillance. Refer to the image below for a visual representation.

الصورة 1: الجبهة view of the DIGOO DG-M1Z camera, showing the lens, IR LEDs, and base with the DIGOO logo.

تتضمن المكونات الرئيسية ما يلي:

• عدسة الكاميرا: يلتقط فيديو فوtage.
• مصابيح LED بالأشعة تحت الحمراء (IR): توفير الإضاءة للرؤية الليلية.
• ميكروفون: لإدخال الصوت أثناء الاتصال ثنائي الاتجاه.
• المتحدث: For audio output during two-way communication and alarms.
• فتحة بطاقة Micro TF: For local video storage (up to 64GB).
• منفذ الطاقة: DC 5V/2A+ input.
• منفذ إيثرنت: للاتصال بالشبكة السلكية.

3. دليل الإعداد

3.1 تشغيل الكاميرا

1. Connect the provided Micro USB power cable (3 meters long) to the camera's power port.
2. Plug the other end of the cable into a DC 5V/2A+ power adapter (ensure the adapter provides sufficient current).
3. سيتم تشغيل الكاميرا وبدء تسلسل بدء التشغيل.

3.2 Installing the "Digoo Eye" App

The "Digoo Eye" application is required to configure and operate your camera. It is available for iOS, Android, and Windows PC.

1. For mobile devices, search for "Digoo Eye" in your device's app store (Google Play Store for Android, Apple App Store for iOS).
2. قم بتحميل وتثبيت التطبيق.
3. For Windows PC, download the client software from the official DIGOO webالموقع (إن وجد).

Image 2: A smartphone displaying the "Digoo Eye" application interface, showing a live camera feed and control options.

3.3 تكوين الشبكة

The camera supports both wireless (Wi-Fi) and wired network connections. Note: The camera only supports 2.4GHz Wi-Fi networks, not 5GHz.

3.3.1 Wireless Connection (Acoustic Smart Link)

1. تأكد من أن جهازك المحمول متصل بشبكة Wi-Fi بتردد 2.4 جيجاهرتز.
2. Open the "Digoo Eye" app and follow the on-screen instructions to add a new device.
3. Select the "Acoustic smart link configuration" option.
4. The app will guide you through entering your Wi-Fi password and using sound to pair the camera.

3.3.2 اتصال سلكي

1. قم بتوصيل كابل إيثرنت من جهاز التوجيه الخاص بك إلى منفذ الإيثرنت الخاص بالكاميرا.
2. ستتصل الكاميرا بالشبكة تلقائيًا.
3. Open the "Digoo Eye" app and follow the instructions to add a new device, selecting the wired connection option.

4. تعليمات التشغيل

4.1 مباشر View والتحكم في الدوران/الإمالة

Once connected, you can access the live video feed through the "Digoo Eye" app. Use the on-screen controls to pan (horizontal movement) and tilt (vertical movement) the camera lens to adjust the viewزاوية جي.

Image 3: Illustration of key camera functionalities including Pan & Tilt, Two-Way Talking, Inframe Light (IR), and Screeching Alarm.

4.2 الصوت ثنائي الاتجاه

The camera supports two-way audio communication. In the app's live view, tap the microphone icon to speak through the camera's speaker, and listen through your device's speaker to audio captured by the camera's microphone.

Image 4: Depiction of multi-account video sharing and two-way audio communication feature.

4.3 اكتشاف الحركة والتنبيهات

Configure motion detection settings within the "Digoo Eye" app. When motion is detected, the camera can trigger an alarm, send real-time message pushes, and E-mail alerts to your configured accounts.

Image 5: Visual explanation of motion detection functionality, showing alerts and diverse applications.

4.4 التسجيل والتشغيل

Insert a Micro TF card (up to 64GB) into the camera's slot for local video storage. The camera supports continuous recording or event-triggered recording based on your settings. You can review تم تسجيل فوtage directly from the "Digoo Eye" app.

Image 6: A family viewing recorded video, highlighting the record and playback feature with a timeline of events.

4.5 الرؤية الليلية

The camera automatically switches to night vision mode in low-light conditions, utilizing its 11 IR LEDs to provide clear black-and-white video up to 10 meters.

Image 7: Visual comparison demonstrating the clarity of 1080P HD video quality compared to lower resolutions.

5. الصيانة

• تنظيف: امسح عدسة الكاميرا وجسمها برفق بقطعة قماش ناعمة وجافة. تجنب استخدام المواد الكيميائية القاسية أو المواد الكاشطة.
• تحديثات البرامج الثابتة: Periodically check the "Digoo Eye" app for available firmware updates to ensure optimal performance and security.
• مزود الطاقة: Ensure the camera is always connected to a stable DC 5V/2A+ power source.
• الظروف البيئية: Operate the camera within the specified temperature range (-10°C to +60°C) and humidity (RH95% Max). While it can be used indoors or outdoors, ensure it is protected from direct weather exposure if used outdoors.

6. استكشاف الأخطاء وإصلاحها

الكاميرا لا تعمل:

Ensure the power adapter is correctly connected and providing sufficient power (DC 5V/2A+). Try a different power outlet or adapter.

غير قادر على الاتصال بشبكة Wi-Fi:

• Verify your Wi-Fi network is 2.4GHz. The camera does not support 5GHz networks.
• تأكد من صحة كلمة مرور شبكة الواي فاي الخاصة بك.
• تأكد من أن الكاميرا ضمن نطاق جهاز توجيه الواي فاي الخاص بك.
• أعد تشغيل جهاز التوجيه والكاميرا.
• If using acoustic smart link, ensure there is no excessive background noise.

No video feed in the app:

• Confirm the camera is powered on and connected to the network.
• تحقق من اتصالك بالإنترنت.
• Restart the app and the camera.

Micro TF card not recording:

• تأكد من إدخال بطاقة TF بشكل صحيح.
• Check if the TF card is formatted correctly (usually FAT32).
• Verify that recording settings are enabled in the "Digoo Eye" app.
• The card might be full; consider backing up data and formatting or replacing it.

7. المواصفات

8. الضمان والدعم

For warranty information and technical support, please refer to the documentation provided with your purchase or visit the official DIGOO webالموقع. احتفظ بإيصال الشراء الخاص بك كإثبات للشراء في حالة مطالبات الضمان.

For further assistance, you may contact DIGOO customer support through their official channels.
