مقدمة
Thank you for choosing the LINKChef Electric Food Chopper. This versatile 600W appliance is designed to simplify your food preparation tasks, allowing you to chop meat, vegetables, fruits, and even crush ice with ease. Its robust stainless steel bowl and powerful motor ensure efficient and consistent results. Please read this manual thoroughly before first use to ensure safe operation and optimal performance.
Figure 1: LINKChef Electric Food Chopper, Model L1915-2. This image shows the assembled food chopper with its stainless steel bowl and motor unit.
Figure 2: The durable, polished stainless steel bowl of the LINKChef food chopper, designed to resist scratches, bumps, corrosions, and tarnishing.
تعليمات السلامة الهامة
عند استخدام الأجهزة الكهربائية، يجب دائمًا اتباع احتياطات السلامة الأساسية، بما في ذلك ما يلي:
- اقرأ كافة التعليمات قبل استخدام الجهاز.
- للحماية من خطر الصدمة الكهربائية، لا تغمر وحدة المحرك أو السلك أو القابس في الماء أو أي سائل آخر.
- من الضروري المراقبة الدقيقة عند استخدام أي جهاز بواسطة الأطفال أو بالقرب منه.
- افصل الجهاز عن المقبس عند عدم استخدامه، وقبل تركيب أو خلع الأجزاء، وقبل التنظيف.
- تجنب ملامسة الأجزاء المتحركة. الشفرات حادة. تعامل معها بحذر شديد.
- لا تقم بتشغيل أي جهاز به سلك أو قابس تالف أو بعد تعطل الجهاز أو سقوطه أو تلفه بأي شكل من الأشكال.
- قد يؤدي استخدام الملحقات غير الموصى بها أو المباعة من قبل الشركة المصنعة إلى نشوب حريق أو حدوث صدمة كهربائية أو إصابة.
- لا تستخدمه في الهواء الطلق.
- لا تترك السلك يتدلى على حافة الطاولة أو المنضدة أو يلامس الأسطح الساخنة.
- لا تضعه على أو بالقرب من موقد غاز أو كهرباء ساخن، أو في فرن ساخن.
- لا تستخدم الجهاز في غير الاستخدام المنزلي المقصود.
تحديد الأجزاء
Familiarize yourself with the components of your LINKChef Electric Food Chopper:
الشكل 3: انفجرت view showing the individual components of the LINKChef food chopper, including the motor unit, lid, blades, bowl, and anti-slip mat.
- زر البدء: Located on top of the main body, used to activate the chopping function.
- Main Body (Motor Unit): Contains the 600W motor and controls.
- Food Grade Lid: Transparent lid to cover the bowl during operation, ensuring safety and preventing splashes.
- 4 Bi-level Blades: Sharp stainless steel blades designed for efficient chopping and grinding.
- Stainless Steel Bowl (1.2L): Durable and robust bowl for holding ingredients.
- Anti-slip Rubber Mat: Provides stability and prevents the bowl from sliding during use.
Figure 4: Close-up of the adamantine connector, highlighting its sturdy, wear-resistant design for smooth, durable, and quiet operation.
التجميع والإعداد
Follow these steps to assemble your food chopper before use:
Figure 5: Visual guide for assembling the LINKChef food chopper, showing the four key steps from blade installation to starting operation.
- تثبيت الشفرة: Place the anti-slip rubber mat under the stainless steel bowl. Carefully place the 4 bi-level blade assembly onto the fixed shaft inside the bowl. Ensure it is seated properly.
- Add the Ingredients: Cut your ingredients into small, manageable pieces (approximately 1-2 inches) and add them into the stainless steel bowl. Do not overfill the bowl; ensure ingredients are below the maximum fill line.
- Install Main Body: Place the food grade lid onto the bowl, aligning it correctly. Then, place the main body (motor unit) onto the lid, turning it slightly to lock it into place. Ensure all parts are securely assembled.
- بدء العمل: Plug the chopper into a power outlet. Press the start button on top of the main body to begin chopping. Use short pulses for coarse chopping or hold for finer results.
Operating Your Food Chopper
The LINKChef Electric Food Chopper features a pulsing button for ultimate control over your chopping results:
Figure 6: Illustration demonstrating the pulsing button for precise control and examples of soft (fruits, garlic, peppers, onions) and hard (nuts, meats, beans, carrots) ingredients suitable for chopping.
- Pulsing Action: Press and release the start button in short bursts to achieve desired consistency. This method is ideal for coarse chopping or when you need more control over the texture.
- التشغيل المستمر: For finer chopping or pureeing, hold down the start button. Do not operate continuously for more than 30 seconds to prevent motor overheating. Allow the motor to rest between cycles.
- تحضير المكونات: For best results, cut larger ingredients into smaller, uniform pieces before placing them in the bowl. Remove any bones from meat or hard pits from fruits.
- Processing Different Ingredients:
- Soft Ingredients: Fruits, garlic, peppers, onions. These typically require shorter pulsing times.
- Hard Ingredients: Nuts, meats, beans, carrots. May require slightly longer pulsing or continuous operation, but always monitor to avoid over-processing.
- سحق الجليد: Use small ice cubes. Pulse briefly until desired consistency is achieved.
- قفل الأمان: The chopper will only operate when the main body is correctly assembled and locked onto the lid and bowl.
التنظيف والصيانة
Proper cleaning and maintenance will extend the life of your LINKChef Food Chopper:
Figure 7: Components of the food chopper (bowl, lid, blades, anti-slip mat) shown being easily cleaned under running water, emphasizing that the main motor unit should not be exposed to liquid.
- افصل الجهاز دائمًا قبل التنظيف.
- Bowl, Lid, and Blades: These parts are dishwasher safe. Alternatively, they can be washed by hand with warm, soapy water. Rinse thoroughly and dry immediately. Handle blades with extreme care as they are very sharp.
- Main Body (Motor Unit): The main body should لا be touched with any liquid. Wipe the exterior of the motor unit with a damp قماش. لا تغمره في الماء أو أي سائل آخر.
- سجادة مانعة للانزلاق: يغسل بالماء الدافئ والصابون ويجفف جيداً.
- تخزين: Store the assembled chopper in a dry place, away from direct sunlight and heat.
استكشاف الأخطاء وإصلاحها
If you encounter any issues with your food chopper, please refer to the following table:
| مشكلة | السبب المحتمل | حل |
|---|---|---|
| الجهاز لا يعمل. | Not plugged in; parts not assembled correctly; motor overheated. | Ensure plug is securely in outlet. Check that the bowl, lid, and motor unit are correctly locked into place. Unplug and let cool for 30 minutes if motor feels hot. |
| لا يتم تقطيع المكونات بالتساوي. | Bowl is overfilled; ingredients are too large; not enough pulsing. | Reduce the amount of ingredients. Cut ingredients into smaller, more uniform pieces. Use short, controlled pulses. |
| يبدو أن المحرك يعاني من إجهاد أو يتوقف. | Too much load; hard ingredients; motor overheating. | Reduce the quantity of ingredients. Ensure ingredients are suitable for chopping. Unplug and allow the motor to cool down. |
| Lid or bowl is difficult to remove. | Parts are tightly sealed after use. | Ensure the motor unit is fully disengaged. Gently twist and lift. |
إذا استمرت المشكلة بعد تجربة هذه الحلول، فيرجى الاتصال بدعم العملاء.
مواصفات المنتج
- ماركة: لينك شيف
- رقم الموديل: ل1915-2
- قوة: 600 واط
- مادة الوعاء: الفولاذ المقاوم للصدأ
- مادة الشفرة: الفولاذ المقاوم للصدأ
- سعة الوعاء: حوالي 1.2 لترًا
- أبعاد المنتج (الطول × العرض × الارتفاع): 19.28 x 19.28 x 22.99 cm (7.59 x 7.59 x 9.05 inches)
- وزن السلعة: 1.29 كيلوغرامًا (2.84 رطلاً)
- أجزاء قابلة للغسل في غسالة الأطباق: Yes (Bowl, Lid, Blades, Anti-slip Mat)
- رمز المنتج العالمي: 756244217123
الضمان ودعم العملاء
LINKChef products are manufactured to the highest quality standards. For information regarding warranty coverage, please refer to the warranty card included with your purchase or visit the official LINKChef website. If you have any questions, concerns, or require technical assistance, please do not hesitate to contact LINKChef customer support. Please have your model number (L1915-2) and purchase details ready when contacting support.
For the most up-to-date contact information, please visit the official LINKChef webأو راجع عبوة المنتج.
