EMKE 50x70cm LED Bathroom Mirror Cabinet Instruction Manual

1. المقدمة

Thank you for choosing the EMKE LED Bathroom Mirror Cabinet. This cabinet is designed to enhance your bathroom with its modern aesthetics and practical features, including adjustable LED lighting, an anti-fog function, and an integrated power outlet. Please read this manual thoroughly before installation and use to ensure safe operation and optimal performance.

2. تعليمات السلامة

• تأكد من فصل مصدر الطاقة قبل التثبيت أو الصيانة أو التنظيف.
• يجب أن يتم إجراء التثبيت بواسطة كهربائي مؤهل وفقًا للوائح الأسلاك المحلية.
• Do not use abrasive cleaners or sharp objects on the mirror surface or cabinet.
• This product is intended for indoor use only, specifically in bathrooms.
• Do not overload the internal power outlet. It is designed for low-power devices like electric shavers or toothbrushes.
• Keep children away from the product during installation and ensure they do not play with electrical components.

3. محتويات العبوة

يرجى التأكد من وجود جميع المكونات وعدم تلفها قبل المتابعة في عملية التثبيت:

• 1 x EMKE LED Bathroom Mirror Cabinet
• 1 x Mounting Accessories Kit (screws, wall plugs, etc.)
• 1 × دليل التعليمات

4. المواصفات

ملحوظة: Please measure your installation space carefully before mounting.

Image: Product dimensions and key features.

5. الإعداد والتثبيت

The EMKE mirror cabinet comes pre-assembled for easier installation. Installation typically takes 10-15 minutes with two people.

5.1 الأدوات المطلوبة (غير متضمنة)

• حفر
• شريط قياس
• قلم رصاص
• مستوى
• مفك البراغي

5.2 خطوات التثبيت

1. تحضير الحائط: Choose a suitable location on a solid wall, away from water sources. Ensure there are no hidden electrical wires or pipes.
2. حدد نقاط الحفر: Use a measuring tape and pencil to mark the desired height and width for the mounting holes on the wall. Use a level to ensure the marks are perfectly horizontal.
3. ثقوب الحفر: Drill holes at the marked points using an appropriate drill bit for your wall type. Insert the wall plugs provided in the mounting kit.
4. تركيب الخزانة: Carefully lift the cabinet and align the mounting brackets on the back of the cabinet with the drilled holes. Secure the cabinet to the wall using the screws provided. Ensure it is firmly attached and stable.
5. التوصيل الكهربائي: Connect the cabinet's electrical wiring to your household power supply. This step يجب be performed by a qualified electrician. Ensure all connections are secure and insulated.
6. وظيفة الاختبار: Once installed, restore power and test all functions: lighting, dimming, color temperature change, anti-fog, and the internal power outlet.

Image: Interior storage and hinge mechanism.

6. تعليمات التشغيل

The EMKE mirror cabinet features intuitive touch controls for its various functions.

6.1 التحكم في إضاءة LED

• تشغيل/إيقاف التشغيل: Touch the main power button on the mirror surface to turn the LED lights on or off.
• تغيير درجة حرارة اللون: With the lights on, repeatedly touch the color temperature button to cycle through Warm White (3000K), Neutral White (4000K), and Cool White (6500K).
• ضبط السطوع (التعتيم): With the lights on, press and hold the brightness button to adjust the light intensity from 10% to 100%. Release when the desired brightness is reached.
• وظيفة الذاكرة: The cabinet will remember your last used light color and brightness settings when turned off and on again.

Image: Adjustable light colors and dimming feature.

6.2 وظيفة مقاومة الضباب

• تفعيل خاصية منع الضباب: Touch the dedicated anti-fog button on the mirror surface to activate the defogger. The anti-fog function operates independently.
• تعطيل خاصية منع الضباب: Touch the anti-fog button again to turn it off.
• The anti-fog function ensures a clear reflection even after hot showers. It has an automatic shut-off after 3 hours for energy saving.

Image: Anti-fog function in use.

6.3 منفذ طاقة مدمج

• A convenient shaver socket is located inside the upper right section of the cabinet.
• Use this outlet to charge low-power electrical devices such as electric shavers or toothbrushes.
• مهم: Do not connect high-power appliances to this outlet.

Image: Using the integrated power outlet.

6.4 Wall Switch Support

• The mirror cabinet supports control via an external wall switch.
• For wall switch control to function, the touch switch on the mirror cabinet must remain in the 'ON' position.

Image: Wall switch compatibility.

7. الصيانة

7.1 التنظيف

• احرص دائمًا على فصل الطاقة قبل التنظيف.
• استخدمي قطعة قماش ناعمةamp cloth and a mild, non-abrasive glass cleaner for the mirror surface.
• For the cabinet exterior, use a soft, damp قطعة قماش بصابون خفيف وماء.
• Do not spray cleaning solutions directly onto the mirror or electrical components. Apply to the cloth first.
• Wipe dry immediately with a clean, dry cloth to prevent water spots.

7.2 العناية العامة

• Avoid exposing the cabinet to excessive moisture or direct water spray.
• Regularly check electrical connections for any signs of wear or damage. If any issues are found, consult a qualified electrician.
• Ensure the cabinet doors close smoothly. The soft-close hinges are designed for durability but avoid forcing the doors.

8. استكشاف الأخطاء وإصلاحها

If you encounter any issues with your EMKE mirror cabinet, please refer to the following common problems and solutions:

If the problem persists after attempting these solutions, please contact EMKE customer support.

9. الضمان والدعم

EMKE is committed to providing high-quality products and excellent customer service.

• ضمان: يأتي هذا المنتج مع ضمان لمدة 2 سنوات من تاريخ الشراء، بما في ذلك تغطية عيوب التصنيع.
• الإرجاعات: A سياسة الإرجاع خلال 14 يومًا is offered for your convenience. Please refer to your retailer's return policy for specific details.
• دعم العملاء: For any questions, technical assistance, or warranty claims, please contact EMKE customer service through the retailer where you purchased the product or visit the official EMKE webموقع.

يرجى الاحتفاظ بإثبات الشراء لأغراض الضمان.
