1. المقدمة
The Jonard Tools Wispy CF-200 is a professional-grade wireless inspection camera designed for inspecting hard-to-reach areas. This device features app-controlled variable focus, an "Always Up" viewing mode, and fast charging capabilities. It is suitable for various applications, including electrical, home inspection, automotive, and plumbing tasks.
2. محتويات المجموعة
The Wispy CF-200 kit includes the following components:
- Wispy Inspection Camera
- 5ft Telescoping Pole
- Cell Phone Wrist Band
- رقبة الإوزة المرنة
- قضيب قصير
- Hook and Magnet Attachments
- Thread Adapters (8 pieces)
- كابل شحن USB-C
- حلقات O احتياطية
- حقيبة حمل واقية
- دليل التعليمات
Image: The complete Jonard Tools Wispy CF-200 kit, including the camera, telescoping pole, wrist band, various adapters, and carrying case.
3. الإعداد
3.1 شحن الكاميرا
Before initial use, fully charge the Wispy CF-200 camera. Connect the provided USB-C charge cable to the camera's USB-C Charging Port and a suitable USB power source. The Power/Charging Indication LED will illuminate during charging and change status when fully charged.
3.2 تثبيت التطبيق
Download the free Wispy App from your device's app store (available for iOS and Android). Install the app on your smartphone or tablet.
3.3 Connecting to Your Smart Device
- Power on the Wispy CF-200 camera using the Power Switch.
- On your smart device, navigate to your Wi-Fi settings.
- Connect to the Wi-Fi hotspot broadcast by the Wispy camera. The network name will typically start with "Wispy-".
- Open the Wispy App. The camera's live feed should now be visible.
الصورة: مفصلة view of the Wispy CF-200 camera, showing the USB-C charging port, power switch, camera lens, and adjustable LEDs.
4. تعليمات التشغيل
4.1 تشغيل/إيقاف التشغيل
Press and hold the Power Switch located on the rear of the camera to turn the device on or off.
4.2 إرفاق الملحقات
The camera features a ¼-20UNC thread for connecting to the telescoping pole, flexible gooseneck, short rod, or other compatible accessories. Ensure attachments are securely fastened.
Image: A user demonstrating the Wispy CF-200 attached to a telescoping pole for extended reach.
4.3 ميزات التطبيق
- البث المباشر: The app displays a real-time 720p video feed from the camera.
- Image/Video Capture: Use the app to capture photos or record videos directly to your smart device.
- التكبير الرقمي: Utilize the digital zoom function within the app to view objects closer.
- Variable Focus Lens: Adjust the focus through the app for clear viewing, even at close distances (as close as 2.5 inches / 6 cm).
- Adjustable LEDs: Control the brightness of the integrated LEDs via the app to optimize visibility in dark environments.
- "Always Up" Viewوضع التشغيل: Access the app's settings screen to enable "Always Up" mode. This feature automatically rotates the image to maintain a correct upright orientation regardless of the camera's physical position, eliminating image spin.
Image: Illustration of the Wispy CF-200's adjustable LEDs providing varying levels of illumination for improved visibility.
Image: A user's wrist with a smartphone displaying the "Always Up" viewing mode, showing a stable image despite the camera's orientation.
5. الصيانة
To ensure optimal performance and longevity of your Wispy CF-200 camera:
- Keep the camera lens clean using a soft, dry cloth. Avoid abrasive materials.
- Store the camera and accessories in the provided protective carrying case when not in use.
- تجنب تعريض الجهاز لدرجات الحرارة الشديدة أو الرطوبة.
- Regularly check the USB-C port for debris and clean if necessary.
6. استكشاف الأخطاء وإصلاحها
If you encounter issues with your Wispy CF-200, refer to the following common solutions:
| مشكلة | السبب المحتمل | حل |
|---|---|---|
| الكاميرا لا تعمل | Low battery; Power switch not engaged | Charge the camera fully; Ensure power switch is pressed firmly. |
| لا يمكن الاتصال بشبكة Wi-Fi | Camera not powered on; Incorrect Wi-Fi selection; Device too far from camera | Ensure camera is on; Select the correct "Wispy-" network; Move smart device closer to camera (within 50ft/15m). |
| No image in app | App not open; Wi-Fi not connected; Camera lens obstructed | Open the Wispy App; Verify Wi-Fi connection; Clean the camera lens. |
| جودة الصورة رديئة | Lens dirty; Insufficient lighting; Incorrect focus | Clean the lens; Adjust LED brightness in app; Adjust focus in app. |
| عمر البطارية قصير | Battery not fully charged; Continuous use of LEDs | Ensure full charge before use; Reduce LED brightness when not needed. |
7. المواصفات
- نموذج: سي اف-200
- الشركة المصنعة: Jonard Tools
- وزن السلعة: 12.5 أونصات
- أبعاد المنتج: 11.65 × 5.35 × 2.51 بوصة
- نوع البطارية: ليثيوم أيون (مطلوب 1، متضمن)
- متوسط عمر البطارية: Approximately 90 minutes (continuous use)
- دقة التقاط الفيديو: 720 بكسل
- نطاق التركيز الماكرو: 6 سم (2.5 بوصة)
- النطاق اللاسلكي: حتى 50 قدم (15 أمتار)
8. الضمان والدعم
The Jonard Tools Wispy CF-200 comes with a "Made For Life" warranty. For detailed warranty information, technical support, or service inquiries, please contact Jonard Tools directly through their official webالموقع أو قنوات خدمة العملاء.
