SCHULTE Regalwelt PowerMAX Shelving Unit Instruction Manual

1. المقدمة

This manual provides detailed instructions for the assembly, operation, and maintenance of your SCHULTE Regalwelt PowerMAX shelving unit. Please read this manual thoroughly before beginning assembly to ensure safe and correct installation and use.

The SCHULTE Regalwelt PowerMAX shelving unit is a robust, versatile storage solution designed for various environments such as workshops, garages, cellars, and kitchens. It features a tool-free slot-in system for quick assembly and adjustable shelves to accommodate different item sizes.

2. معلومات السلامة

تحذير:

• لا تتجاوز الحد الأقصى للحمل وهو 65 كجم لكل رف.
• The total maximum load capacity for the entire unit is 260 kg.
• Ensure correct assembly to prevent injury or material damage.
• Always distribute weight evenly across the shelves.
• Do not climb on the shelving unit.
• For stability, especially with heavy loads or in areas prone to movement, consider anchoring the unit to a wall (anchoring hardware not included).
• احتفظ بالأجزاء الصغيرة بعيدًا عن متناول الأطفال أثناء التجميع.

3. محتويات العبوة

Before starting assembly, verify that all parts are present and undamaged. If any parts are missing or damaged, please contact customer support.

• 4 x PowerMAX Shelves (4 cm height)
• 8 x Upper Angle Profiles
• 4 x Lower Angle Profiles
• 4 × قدم بلاستيكية
• دليل تعليمات التجميع (1 × 1)

الشكل 3.1: انتهىview من الميزات والمكونات الرئيسية.

4. الإعداد والتجميع

The SCHULTE Regalwelt PowerMAX shelving unit features a tool-free slot-in system for quick and easy assembly. No complex screws are required.

4.1 الأدوات المطلوبة

• Rubber mallet (recommended for securing connections)
• Work gloves (recommended for handling metal parts)

4.2 خطوات التجميع

1. إعداد المنطقة: اختر سطحًا مستويًا وثابتًا للتجميع. تأكد من وجود مساحة كافية حول الوحدة.
2. Assemble the Vertical Frames:
   • Connect the upper and lower angle profiles to form the vertical uprights. The divided angle profiles can be easily assembled.
   • Insert the plastic feet onto the bottom of the lower angle profiles.


   Figure 4.1: Detail of the slot-in system for effortless assembly.

3. قم بتثبيت الرفوف:
   • Begin by attaching the bottom shelf to the vertical frames. Ensure the shelf's tabs align with the slots on the uprights.
   • Gently tap with a rubber mallet to secure the connections.
   • Attach the top shelf in the same manner.
   • The remaining two shelves can be inserted at your desired height. The shelves are adjustable in 13 cm increments.


   Figure 4.2: Adjustable shelf height for flexible storage.

4. التحقق النهائي: Once all shelves are in place, ensure all connections are secure and the unit is stable.

For visual guidance, an assembly video may be available from the manufacturer. Please check the manufacturer's webلمزيد من المعلومات.

5. التشغيل والاستخدام

The SCHULTE Regalwelt PowerMAX shelving unit is designed for versatile storage in various environments.

• تطبيق متعدد الاستخدامات: Ideal for workshops, garages, cellars, and kitchens.
• رفوف قابلة للتعديل: The shelves can be adjusted in height to accommodate items of different sizes, such as car tires, toolboxes, storage bins, and more.
• توزيع الحمل: Always distribute the weight evenly across the shelves to maintain stability and prevent damage.

الشكل 5.1: مثالamples of versatile use in different environments.

6. الصيانة

To ensure the longevity and optimal performance of your shelving unit, follow these maintenance guidelines:

• تنظيف: امسح الأسطح المعدنية بـamp cloth and mild detergent. Avoid abrasive cleaners or harsh chemicals that could damage the powder coating.
• تقتيش: Periodically check all connections to ensure they remain secure. Re-tap with a rubber mallet if any connections feel loose.
• إدارة الأحمال: إعادة بانتظامview the items stored on the shelves to ensure the load capacity is not exceeded and weight is distributed evenly.
• منع الصدأ: While the unit has a powder coating, avoid prolonged exposure to excessive moisture to prevent rust, especially in high-humidity environments.

7. استكشاف الأخطاء وإصلاحها

إذا واجهت أي مشاكل مع وحدة الرفوف الخاصة بك، فراجع المشاكل والحلول الشائعة التالية:

8. المواصفات

الشكل 8.1: أبعاد المنتج.

9. الضمان والدعم

For warranty information, product support, or to order replacement parts, please contact SCHULTE Regalwelt customer service. Details can typically be found on the manufacturer's official webالموقع أو من خلال نقطة الشراء الخاصة بك.

يرجى تجهيز رقم الطراز (4056397004448) وتاريخ الشراء عند الاتصال بالدعم.
